- General Information
- Manufacturer
- Atdec Pty Ltd
- Manufacturer Website Address
- http://www.atdec.com.au
- Brand Name
- Atdec
- Product Type
- Wall Mount
The TH-2250-VTP is a compact wall mount with tilt and pan movement capabilities. Installation is simple and hassle-free, with all mounting hardware included. The quick attachment inhook-onin mechanism makes installation and replacement of the display a quick exercise. Once attached, viewing angle can be optimized using simple tool-free tilt and pan adjustment features.
- Product Information
- Device Supported
- Flat Panel Display
- Number of Displays Supported
- 1
- Maximum Load Capacity
- 30 kg
- Features
- Tilt
- Pan
- Adjustable
- Rotate
- Durability
- Theft Resistant
- Physical Characteristics
- Color Family
- Black
- Product Color
- Black
- VESA Mount Compatible
- Yes
- Mounting Pattern
- 50 x 50
- 75 x 75
- 100 x 100
- 200 x 100
- 200 x 200
- Product Material
- Steel
- Miscellaneous
- Package Contents
- 2 x Wall Mount Screw
- 2 x Nylon Anchor
- 4 x M4 Washer
- 4 x M5 Washer
- 4 x M6 Washer
- 4 x M6 x 8mm Screw
- 4 x M6 x 12mm Screw
- 4 x M5 x 8mm Screw
- 4 x M5 x 12mm Screw
- 4 x M4 x 8mm Screw
- 4 x M4 x 12mm Screw
- Additional Information
- Adjustable pan: -/+15°
- Distance from wall: 82mm
- Quick release mechanism for fast display attachment or removal with a security feature
- Compatibility
- LED
- LCD
- Assembly Required
- Yes
