The DP750 creates an immersive DECT network to enable mobile and efficient movement in your organization. A powerful mobile solution and user flexibility is achieved when paired with up to five phones in Grandstream's DECT series. The DP750 supports a range of up to 300 meters outdoors and 50 meters indoors. This base station delivers up to 10 SIP accounts and 5 concurrent calls while also offering essential call control features and functionalities, such as 3-way conferencing, call forward and call transfer. A seamless, unified interaction can be achieved through the DP750, by giving all handsets a shared SIP account from the DP750. The DP750 supports a variety of auto-provisioning methods and TLS/SRTP/HTTPS encryption security.
- General Information
- Manufacturer
- Grandstream Networks, Inc
- Manufacturer Website Address
- http://www.grandstream.com
- Brand Name
- Grandstream
- Product Type
- Phone Base Station
- Technical Information
- Wireless Technology
- DECT
- Wireless Operating Distance
- 300 m
- Minimum Operating Frequency
- 1.92 GHz
- Maximum Operating Frequency
- 1.93 GHz
- Number of Channels
- 5
- Physical Characteristics
- Height
- 28.5 mm
- Width
- 130 mm
- Depth
- 90 mm
- Weight (Approximate)
- 143 g
- Miscellaneous
- Additional Information
- 5 LED indicators: Power, Network, Register, Call, DECT
- Reset button, Pairing/Paging button
- One 10/100 Mbps auto-sensing Ethernet port with integrated PoE
- Universal Power Supply Input AC 100-240V 50/60Hz; Output 5VDC 1A; Micro-USB connection
- PoE: IEEE802.3af Class 1, 0.44W-3.84W
- SIP RFC3261
- TCP/IP/UDP
- RTP/RTCP
- HTTP/HTTPS
- ARP/RARP
- ICMP
- DNS (A record
- SRV
- NAPTR)
- DHCP
- PPPoE
- SSH
- TFTP
- NTP
- STUN
- SIMPLE
- LLDP-MED
- LDAP
- TR-069
- 802.1x
- TLS
- SRTP
- IPv6 (Pending)
- G.711µ/a-law
- G.723.1
- G.729A/B
- G.726-32
- iLBC
- G.722
- OPUS
- G.722.2/AMR-WB (spe-cial order)
- in-band and out-of-band DTMF (in audio
- RFC2833
- SIP INFO)
- VAD
- CNG
- PLC
- AJB
- Hold
- transfer
- forward
- 3-way conference
- downloadable phonebook (XML
- LDAP
- up to 3000 entries)
- call waiting
- call log (up to 300 records)
- auto answer
- flexible dial plan
- music on hold
- server redundancy and fail-over
- User and administrator level access control
- MD5 and MD5-sess based authentica-tion
- 256-bit AES encrypted configuration file
- TLS
- SRTP
- HTTPS
- 802.1x media access control
- DECT authentication & encryption
- Certifications & Standards
- FCC: Part 15D, Part 15B
- CE: EN60950, EN301489-1-6, EN301406
- RCM: AS/NZS60950
- ANATEL: #2288-16-9452
